Labeling machine Vertical Type
Labeling machine Vertical Type
€5,500 (EUR)
Delivered
Location:Bologna, Italy
Available quantity:1
or
Call +359 89 426 6899
Description
This is a Multi-functional Right Corner Labeling Machine with Standard type.
For precise positioning labeling, the length of one side of the box should be not exceed 21cm. (If no precise
positioning required, the box width within the rang of 1cm~50cm is suitable to use).
The maxium size of box labeling side is 21cm, if over than 21cm, it needs to customize broadened panel, with an extra cost
Specifications
| Manufacturer | BBS |
| Model | ZJTB-02 |
| Condition | New |
| Stock Number | BBS251301 |
| Applicable box shape to label: | Box with hook at the edge of the box |
| Applicable Label Range: | 15~25mm, one single row.; if 26mm~30mm（need customized) |
| Machine Dimension: | about 400(L)*200 (W)*310(H)mm |
| Applicable Label Thickness: | 0.05~0.08mm, suitable for transparent & non transparent sticker |
| Space Between Labels: | over than 1mm |
| Acceptable Back Paper Thickness of Label: | 0.04~0.07mm |
| Applicable Label Roll Range: | Outer diameter≤ 200mm, Inner diameter 76mm |
| Weight: | net weight about 13kgs |
| Voltage /Power supply: | AC 110~240V 50Hz,100W |
| Labeling Speed: | 50 to 90 pcs/min (Actual speed depends on operator's operation proficiency) |
| Suitable Box Size Range for Labeling: | For precise positioning labeling, the length of one side of the box should be not exceed 21cm. (If no precise positioning required, the box width within the rang of 1cm~50cm is suitable to use) |
